FR400, Flush-Face Hydraulic Coupler, Female Half

FR400, Flush-Face Hydraulic Coupler, Female Half

FR400, Flush-Face Hydraulic Coupler, Female Half

Price
Original price was: $274.21.Current price is: $137.11.
Free shipping over $40 Calculated automatically
Reliable delivery Tracking provided when shipped
Easy returns View return policy
Secure payment Your payment details are protected

Features

  • Featuring “Push-to-connect” operation, to guarantee good connection every time
  • Hydraulic Tool Manufacters Association recognized for safety and performance
  • Dimension A is total length when male and female halves are connected.
  • Flush-face, zero-leak operation for minimal spillage
  • 3/8″ High Flow “Flush-face” Couplers

Specifications

  • Shipping Weight: 0.65 lbs
  • Product Line: Industrial Tools
  • Type: Coupler
  • Country of Origin: United States
  • News Feed Product Group: Couplers
  • Sub Types: Flush-face Coupler

Dimensions

  • Dimension E: 1.23 In | 31 Mm
  • Dimension F: 1.06 In | 27 Mm
  • Dimension C: 3/8 NPTF In | 3/8 nptf Mm
  • Dimension G: 1.12 In | 29 Mm
  • Dimension A: 4.36 In | 111 Mm
  • Dimension B: 2.85 In | 72 Mm
  • Dimension D: 1.23 In | 31 Mm

Coupler

  • Maximum Flow Capacity: 2500 in/min | 40 L/min
  • Maximum Operating Pressure: 10000
